Concrete Vibrating Table, ASTM

STANDARDS : AASHTO R 39 , AASHTO T 23 , ASTM C192/192M , ASTM C31/31M

Vibrating Table is used in consolidating fresh concrete in molds when forming cylinder and beam specimens.

Please Contact With Us For More Information

Description

Description

Product Code Product Description
PRS- CVIBT1 Concrete Vibrating Table, ASTM , 115V / 60Hz
PRS- CVIBT2 Concrete Vibrating Table, ASTM , 230V / 50Hz)



Concrete Vibrating Table, ASTM

STANDARDS : AASHTO R 39 , AASHTO T 23 , ASTM C192/192M , ASTM C31/31M

Vibrating Table is used in consolidating fresh concrete in molds when forming cylinder and beam specimens.

The unit has a 20x20in (508x508mm) large platform with a load capacity of up to 300lb (136kg) and is rated at 3,600 vibrations per minute.

The electromagnetic table comes with a separate Control unit with on/off switch and rheostat to regulate amplitude.

*** Power cable to the vibrating table is user-supplied.

Reviews (0)

Leave a Reply

Your email address will not be published. Required fields are marked *

  • Rating

TECHNICAL SPECIFICATIONS

300lb load capacity;

3,600vpm

Large 20x20in platform

Separate Control box


Included Items

Vibrating Table (115V/60Hz or 230V/50Hz)

Power Pulse 115/230V WT Control
