High Capacity Sieve Shaker

STANDARDS : EN 1339, 1367-1; TS 2824

High Capacity Sieve Shaker is ideal for sizing large quantities of crushed stones, sand, gravel, slag, coal, coke, ores, pellets and similar materials.

Please Contact With Us For More Information



Description

Product Code Product Description
PRS-GHCSS0310 High Capacity Screen Shaker Time-Controlled, 220-240 V 50-60 Hz
PRS-GHCSS0310/110 High Capacity Screen Shaker Time-Controlled, 110 V 60 Hz
PRS-GHCSS0315 Pan
PRS-GHCSS0316 Soundproof Safety Cabinet



High Capacity Sieve Shaker

STANDARDS : EN 1339, 1367-1; TS 2824

High Capacity Sieve Shaker is ideal for sizing large quantities of crushed stones, sand, gravel, slag, coal, coke, ores, pellets and similar materials.

The screen shaker has a capacity of approx. 30 kg of sample. To be use with 667x452x67 mm dimension screens.

The shaker has 5 screens and 1 pan capacity.

PRS-GHCSS0310 model is time-controlled Various sized wowen wired from 100 mm (4”) to 4 mm (no.5) or perforated plate from 125mm to 5.6mm screen

trays are available on request.

PRS-GHCSS0316 Soundproof Safety Cabinet is manufactured from sheet steel lined internally with soundproofing material to reduce noise and for

protection from dust.


*** Screen trays and Soundproof Safety Cabinet (PRS-GHCSS0316) should be ordered separately.

The PRS-GHCSS0310  is supplied complete with;

Pan (PRS-GHCSS0315)

Reviews

There are no reviews yet.


Be the first to review “High Capacity Sieve Shaker”

SCREEN SHAKER

Dimension 587x787x850 mm
Weight (approx.) 170 kg
Power 550 W



SCREEN TRAYS

Dimensions 667x452x67 mm
Weight (approx.) 7 kg
