Alcali Silica Reaction Test Water Bath
Alcali Silica Reaction Test Water Bath ; In this test chamber concrete specimen are stored at a temperature between 20°C and 70°C at nearly 100% rel.
Please Contact With Us For More Information
- Description
- TECHNICAL SPECIFICATIONS
Description
| Product Code | Product Description |
| PRS-AALSILB | Alcali Silica Reaction Test Water Bath |
Alcali Silica Reaction Test Water Bath
STANDARDS : NF P18-454, RILEM Test Method TC 191-ARP (Ed.): AAR-4.1, ASTM C1567 -8, ASTM C1293 – 08b, CANADA CSA-A23.2-25A
In this test chamber concrete specimen are stored at a temperature between 20°C and 70°C at nearly 100% rel.
Humidity according to the French standard NF P18-454 (Décembre 2004) Detection of Potential Alkali-Reactivity- Accelerated method for testing aggregate combinations
using concrete prisms.
The temperature deviation herein is below 0.5K
| Application | Storing of ACR test containers at 60°C and nearly 100% rel. Humidity according to RILEM/TC-ARP/01/20 and ASTM C1293 and modifies ASTM C1293 at 60°C |
| Net. size (lxwxh) | 550 x 1000 x 800 mm |
| Shelfs for the test container | 1 |
| Inner cabinet | Stainless steel |
| Sensors | PT100 1/10 DIN B |
| Heating | 2000 kW |
| Weight | App. 66 kg |
| Mains connection | 220 V 50 Hz |
